Hydraulic Vibroflotation Compaction Equipment High Compaction Efficiency Achieved

Marchio:	BVEM
Numero di modello:	BJVH-350-150
MOQ:	1 INSIEME
prezzo:	35000 $
Dettagli dell' imballaggio:	cassa di legno, pallet di legno
Condizioni di pagamento:	、 T/T DI L/C

Informazioni dettagliate

Descrizione del prodotto

Informazioni dettagliate

Luogo di origine:

Certificazione:

CE、ISO 9001:2000、ISO 9001:2008

Documento:

Servizio post-vendita fornito:

Ingegneri disponibili per la manutenzione dei macchinari all'estero

Condizione:

Nuovo

Peso del vibratore:

1700 kg

Nome del prodotto:

Compattazione idraulica con vibroflottazione di fabbricazione cinese da 350-150 Kw

Potenza del motore:

150 chilowatt

Dimensione (L*W*H):

2250*650*340 mm

Garanzia:

1 anno o 2000 ore, a seconda di quale evento si verifica per primo

Colore:

Verde

Livello di olio:

208 lpm

Applicazione:

Compattazione vibrp, sostituzione vibrazioni

Tipo di potenza:

Idraulico

Energia:

150 chilowatt

Frequenza:

42 Hz

Max. VELOCITÀ:

0-2900 giri/min

Diametro della pila:

500-800 millimetri

Blocco alimentatore:

176 chilowatt

Compressore d'aria:

20 m3/min

Garanzia:

1 anno o 2000 ore

Capacità di alimentazione:

600 set/anno

Evidenziare:

Hydraulic Vibroflot compaction equipment

Vibroflotation high efficiency compactor

Hydraulic soil compaction machinery

Descrizione del prodotto

Hydraulic Vibroflotation Compaction Equipment High Compaction Efficiency Achieved

With over 50 years of dedication to the vibroflotation industry, BVEM has focused on the R&D and investment in vibroflotation products. It takes creating high-efficiency, stable and high-quality equipment as its core goal, providing solid and reliable guarantees for customers' vibroflotation projects. The BJVH-350-150 hydraulic vibroflot under its brand is a concentrated embodiment of its technical accumulation and innovative strength.

Working Principle of Hydraulic Vibroflot

This hydraulic vibroflot efficiently converts hydraulic energy into mechanical energy (rotational motion) through a hydraulic motor, driving the eccentric block to generate a strong horizontal excitation force. It has significant core advantages: large output torque, wide speed regulation range, and the ability to achieve stepless speed regulation. It can easily cope with large impact loads, providing both work efficiency and stable power support for vibroflotation construction.

Features of BVEM BJVH-350-150 Hydraulic Vibroflot

0-2900rpm stepless speed regulation, which can flexibly match different construction rhythms and stratum requirements, and accurately control the operation intensity.
It has a wide range of applicable strata. With strong excitation force and optimized structural design, it has stronger penetration. It can work efficiently in both soft soil foundations and gravel-containing strata.
It can continuously output large excitation force and high power, ensuring stable and continuous construction process, and effectively improving pile forming efficiency and project quality.
It does not require a water-cooled motor, breaking through the dependence of traditional construction on water sources, realizing vibroflotation dry method environmental protection construction, and conforming to the concept of green engineering.
It has outstanding high adaptability and can be flexibly mounted on various construction site equipment such as special pump stations, rotary drilling rigs, excavators, and pile frames, adapting to the equipment configuration needs of different construction scenarios and reducing equipment investment costs.

Applications

The BVEM Hydraulic Vibroflot (Model: BJVH-350-150) is a powerful soil improvement tool designed to enhance soil relative density in various construction scenarios. Manufactured in CHINA, this product boasts CE and ISO 9001 certifications, ensuring top-notch quality and performance.

BVEM has always been oriented to the diversified needs of customers, and is deeply engaged in the diversified R&D and innovation of vibroflot equipment: from electric vibroflots to hydraulic vibroflots, it has realized the iterative upgrading of driving methods; from orifice filling vibroflots to bottom discharge vibroflots, it has accurately adapted to the core needs of different construction technologies; it has also broken through the limitations of equipment mounting scenarios, covering all kinds of construction scenarios.

Foundation Construction: The BVEM Hydraulic Vibroflot is ideal for compacting soil and improving its relative density, ensuring stable foundations for buildings and infrastructure.
Road and Highway Projects: Use this vibroflotation machine to enhance soil strength and reduce settling, increasing the lifespan and durability of roads and highways.
Retaining Wall Installation: Improve soil stability and prevent erosion by utilizing the BVEM Hydraulic Vibroflot in retaining wall construction.

Whether you are a contractor, engineer, or construction professional, the BVEM Hydraulic Vibroflot offers a reliable solution for soil improvement tasks. Trust in its quality, performance, and remote control functionality to streamline your projects and achieve excellent results.
